Magnum + Cluster API
In this post, I detail how to install Magnum with the Cluster API to create clusters in Openstack.
· 4 min read
Magnum + Cluster API #
Magnum is Openstack’s native service for container orchestration and supports Kubernetes as a container orchestrator.
The Cluster API (CAPI) is a Kubernetes project to simplify the deployment and management of k8s clusters, and supports several cloud providers, including Openstack.
It is possible to use CAPI with Openstack without needing Magnum. However, in this post, I will introduce the use of CAPI with Magnum. This way, we can create multiple clusters based on defined templates without having to worry about how things are working under the hood. This will provide a Cluster as a Service (CaaS) offering.
k3s #
For the management cluster, that is, the CAPI cluster, we will use k3s.
Follow the official k3s documentation for installation.
Installing k3s #
curl -sfL https://get.k3s.io | sh -
Accessing the k3s cluster #
By default, the k3s configuration file is located at
/etc/rancher/k3s/k3s.yaml
. Therefore, we need to make a configuration change.
First, make a copy of the file to your current location and edit it:
sudo cp /etc/rancher/k3s/k3s.yaml .
# Change the file permissions so you can access it as the current user
sudo chown <user>:<group> k3s.yaml
vim k3s.yaml
Edit the file and change the server address to the IP of the management cluster node.
For example, change it from 127.0.0.1
(localhost
) to 10.0.0.11
.
- server: 127.0.0.1:6443
+ server: 10.0.0.11:6443
Now, use the file to access the cluster.
export KUBECONFIG=k3s.yml
# List all pods to test connectivity
kubectl get pods -A
Installing CAPI on the cluster #
The Cluster API provides great documentation on how to install and test CAPI.
Install clusterctl
on the deploy node.
curl -L https://github.com/kubernetes-sigs/cluster-api/releases/download/v1.11.1/clusterctl-linux-amd64 -o clusterctl
sudo install -o root -g root -m 0755 clusterctl /usr/local/bin/clusterctl
To verify that clusterctl is the latest version, run
clusterctl version
Before initializing clusterctl
for the Openstack provider, export this
variable.
export CLUSTER_TOPOLOGY=true
Now, initialize the Openstack provider.
# Install ORC (needed for CAPO >=v0.12)
kubectl apply -f https://github.com/k-orc/openstack-resource-controller/releases/latest/download/install.yaml
# Initialize the management cluster
clusterctl init --infrastructure openstack
Configuring Magnum #
Deploy Magnum using kolla
#
Edit the globals.yaml
file in /etc/kolla/
.
# globals.yaml
enable_magnum: true
enable_cluster_user_trust: true
kolla-ansible deploy -i <inventory> --tags common,horizon,magnum
Now, we need to configure Magnum to use the Cluster API to create the clusters.
# Create the Magnum configuration directory
mkdir -p /etc/kolla/config/magnum
# Copy k3s.yaml as the kubeconfig file for Magnum to use
cp k3s.yaml /etc/kolla/config/magnum/kubeconfig
Reconfigure Magnum to use this file and authenticate with the Cluster API management cluster.
kolla-ansible reconfigure -i <inventory> --tags magnum
Downloading a CAPI-compatible image #
You must have at least one Cluster API-compatible image in Openstack.
To do this, we’ll need to download the image and upload it to Openstack.
Next, we download a compatible Ubuntu 22.04 image and upload it to Openstack.
The Kubernetes version used here is v1.27.4
.
export OS_DISTRO=ubuntu # you can change this to "flatcar" if you want to use Flatcar
for version in v1.27.4; do \
[[ "${OS_DISTRO}" == "ubuntu" ]] && IMAGE_NAME="ubuntu-22.04-kube-${version}" || IMAGE_NAME="flatcar-kube-${version}"; \
curl -LO https://object-storage.public.mtl1.vexxhost.net/swift/v1/a91f106f55e64246babde7402c21b87a/magnum-capi/${IMAGE_NAME}.qcow2; \
openstack image create ${IMAGE_NAME} --disk-format=qcow2 --container-format=bare --property os_distro=${OS_DISTRO} --file=${IMAGE_NAME}.qcow2;
done;
Creating a template #
Requirements:
- Load the Openstack admin environment variables
- Have the Magnum client downloaded to the environment (
pip install python-magnumclient
)- To create a Magnum template, you must have an external network, here as
external
export version=v1.27.4
openstack coe cluster template create \
--image $(openstack image show ${IMAGE_NAME} -c id -f value) \
--external-network external \
--dns-nameserver 8.8.8.8 \
--master-lb-enabled \
--master-flavor general.medium \
--flavor general.small \
--network-driver calico \
--docker-storage-driver overlay2 \
--coe kubernetes \
--label kube_tag=${version},availability_zone=nova \
k8s-${version};
Creating a cluster #
openstack coe cluster create \
--cluster-template k8s-v1.27.4 \
--master-count 1 \
--node-count 1 \
k8s-v1.27.4
This command creates a cluster named k8s-v1.27.4
with 1 control node and 1
worker node.
Conclusion #
With this, we have a working and accessible k8s cluster. We can then expose this cluster template as public so that cloud users can transparently create clusters based on the defined templates.
